CDTECH LCD SCREEN S029Q03 | |
manufacturer | CDTECH |
Model Name | S029Q03 |
screen size | 2.9 inch (1/2 cut of 3.5") |
Screen type | a-Si TFT-LCD , LCM |
Resolution | 320(RGB)120, 115PPI |
Pixel configuration | RGB Vertical Stripe |
Display size | 70.08(W)26.284(H) mm |
physical dimension | 76.9(W)37.72(H) 3.46(D) mm |
Visual size | 72.68(W)28.88(H) mm |
Brightness | 300 cd/m² (Typ.) |
Contrast | 400:1 (Typ.) (TM) |
Best angle | 12 o'clock |
Optical mode | TN, Normally White, Transmissive |
Viewing angle | 65/65/55/65 (Typ.)(CR Greater than or equal to 10) |
Responding time | 8/17 (Typ.)(Tr/Td) ms |
Number of color | 262K 61 percent NTSC |
Backlight type | 6S1P WLED , 30K hours , Without Driver |
Panel weight | TBD |
Apply to | Stretched Bar LCD |
Touch function | No touch |
Interface Type | 8/9/16/18-bit 6800/8080 parallel, 6/9/16/18-bit RGB, SPI , 54 pins FPC |
Supply voltage | 3.3/3.3V (Typ.)(VCI/VDDIO) |
Maximum rating | Operating Temp.: -20 70 degree ; Storage Temp.: -30 80 degree |
2.9 inch LCD Panel DISPLAY S029Q03 | |
Q:How can I trace my order of S029Q03 ?
A:we will give you tracking number then you can trace your order from website.
Q:Can I pay my goods S029Q03 by credit card ?
A:Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods S029Q03 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
Q:If I order S029Q03 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
We are one of the professional and experienced suppliers of 2.9 inch LCD Panel DISPLAY S029Q03, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
